SYSTEM SPECIFICATIONS | |||||
---|---|---|---|---|---|
Signal / Noise | > 90 dB | ||||
THD+N (@ 1 kHz) | < 0.1% | ||||
Crosstalk (@ 1 kHz) | > 70 dB | ||||
Technology | Class-D | ||||
Protection | DC Short circuit | ||||
Over heating | |||||
Over load | |||||
Signal limiting | |||||
Cooling | Convection cooled | ||||
Operating temperature | 0° ~ 40° @ 95% Humidity | ||||
Frequency | Response (± 3 dB) | 20 Hz – 20 kHz | |||
Power | Supply | Switching mode | |||
AC Input: 100-120V/220-240V~ 50/60Hz | |||||
Note: Standard voltage and frequency of electricity varies from country to country. Please contact your local distributor to ensure suitable product variant voltage and frequency compatibility. | |||||
Consumption | 426 W | ||||
Inputs | Sensitivity (1W/1m) | 0 dB (1V RMS) | |||
Impedance | 12 kΩ balanced | ||||
Connector | XLR female with Male Linkthrough | ||||
Outputs | Connector | Speakon compatible & 2-pin Euro Terminal Block (5.08 mm) | |||
Power | Consumption | Standby | 0.7 Watt (30 min standby time) | ||
RMS Power | @ 4 Ω Stereo | 2 x 500 W | |||
@ 8 Ω Bridge | 1000 W | ||||
@ 8 Ω Stereo | 2 x 300 W |
PRODUCT FEATURES | ||||
---|---|---|---|---|
Dimensions | 482 x 44 x 330 mm (W x H x D) | |||
Weight | 4.700 kg | |||
Mounting | 19” | |||
Unit height | 1 HE | |||
Construction | Steel | |||
Colours | Black |
