The internal self-resetting network provides optimal overload protection. It features a stunningly designed and elegant looking ABS housing which is fitted with high-quality components.
*The ATEO2S is not compatible with the CleverMount™ mounting system.
VARIANTS
- ATEO2S/B – Black version – 8Ω
- ATEO2S/W – White version – 8Ω
- ATEO2SD/B – Black version – 16Ω
- ATEO2SD/W – White version – 16Ω
SYSTEM SPECIFICATIONS | ||||
---|---|---|---|---|
Speaker type | Full range | |||
Peak power handling | 40 W | |||
Program power handling | 20 W | |||
RMS/AES power handling | 10 W | |||
Impedance | 8 Ω (ATEO2) | |||
16 Ω (ATEO2D) | ||||
Incline angle | Left | 25° | ||
Right | 25° | |||
Bottom | 25° | |||
Top | 15° | |||
Sensitivity (1W/1m) | 83 dB | |||
Sound Pressure (Max. W/1m) | 93 dB | |||
Frequency | Response (± 3 dB) | 120 Hz – 20 kHz | ||
Range (-10 dB) | 100 Hz – 20 kHz | |||
Dispersion | Horizontal | 145° | ||
Vertical | 170° | |||
Drivers | 2” Aluminium full range |
PRODUCT FEATURES | ||||
---|---|---|---|---|
Dimensions | 80 x 136 x 115 mm (W x H x D) | |||
Weight | 0.390 kg | |||
Operating temperature | -20 °C ~ 60 °C | |||
Construction | ABS | |||
Front finish | Steel grill | |||
Colours | Black | |||
White |
